Model:Z4A
Z4A, 3.5kw/7kw/11kw/21kw EV Portable charging – compatible with multiple outlets
no data
Previous: No more data
Product Details
| Basic Information | Product Model: | Z4A Series (3.5KW ) |
| Input Voltage: | 230Vac±15% | |
| Rated Current: | 16A MAX | |
| Rated Power: | 3.5KW | |
| Power Supply: | 1 Phase | |
| Product Specification | Charging Type: | Level 2 |
| Charging Plug: | IEC 62196-2 (Type 2) | |
| Reference Standards: | IEC 61851-1、IEC 62752、IEC 62196-2 | |
| Power Plug: | Type F 16A-1 Phase | |
| Charging Cable: | 3 x 2.5 mm2 + 1 x 0.5 mm2 ( 1 Phase/16A) | |
| APP Control | Share charging pile | |
| Select a Charging Mode | ||
| Set Charging Current | ||
| User lnterface | LCD Indicator | |
| Communication Interface | Bluetooth ; WI-FI | |
| Working Environment | Working Temp.: | -30°C~+50°C |
| Humidity: | 5~95% Non-Condensing | |
| IP Rate: | IP 55 for Controller Box; IP 55 for Charging Plug | |
| Material Performance | Crushing Force: | No Damage Under 5000N |
| Shell: | Fireproof PC | |
| Charging Plug Pin: | Pure Copper Silver Plated | |
| Charging Cable: | Pure Copper Core with TPU Cable Jacket ; Flame Retardant Grade UL94V-0 | |
| Mechanical Life: | >10,000 Times | |
| Electrical Protection | Over current protection ; Residual current protection | |
| Ground protection ; Surge protection | ||
| Over/Under voltage protection | ||
| Over temp protection ; Leakage protection Type A (AC 30mA) / Type A+DC6mA (AC 30mA+DC 6mA) | ||
| Dimension & Package | Control Box Size: | L239*W91*H56 mm / L9.41"*W3.58"*H2.21" |
| Cable Length: | 5Meter /16.4ft/ Customized | |
| Inner Box: | L315*W250*H160 mm / L12.40"*W9.84"*H6.30" | |
| Outer Carton: | L655*W525*H350 mm / L25.79"*W20.67"* H13.78" (8 pieces) | |
| Net Weight: | ≤ 5KG (1 pieces) | |
| Basic Information | Product Model: | Z4A Series (3.5KW ) |
| Input Voltage: | 230Vac±15% | |
| Rated Current: | 16A MAX | |
| Rated Power: | 3.5KW | |
| Power Supply: | 1 Phase | |
| Product Specification | Charging Type: | Level 2 |
| Charging Plug: | IEC 62196-2 (Type 2) | |
| Reference Standards: | IEC 61851-1、IEC 62752、IEC 62196-2 | |
| Power Plug: | Type F 16A-1 Phase | |
| Charging Cable: | 3 x 2.5 mm2 + 1 x 0.5 mm2 ( 1 Phase/16A) | |
| APP Control | Share charging pile | |
| Select a Charging Mode | ||
| Set Charging Current | ||
| User lnterface | LCD Indicator | |
| Communication Interface | Bluetooth ; WI-FI | |
| Working Environment | Working Temp.: | -30°C~+50°C |
| Humidity: | 5~95% Non-Condensing | |
| IP Rate: | IP 55 for Controller Box; IP 55 for Charging Plug | |
| Material Performance | Crushing Force: | No Damage Under 5000N |
| Shell: | Fireproof PC | |
| Charging Plug Pin: | Pure Copper Silver Plated | |
| Charging Cable: | Pure Copper Core with TPU Cable Jacket ; Flame Retardant Grade UL94V-0 | |
| Mechanical Life: | >10,000 Times | |
| Electrical Protection | Over current protection ; Residual current protection | |
| Ground protection ; Surge protection | ||
| Over/Under voltage protection | ||
| Over temp protection ; Leakage protection Type A (AC 30mA) / Type A+DC6mA (AC 30mA+DC 6mA) | ||
| Dimension & Package | Control Box Size: | L239*W91*H56 mm / L9.41"*W3.58"*H2.21" |
| Cable Length: | 5Meter /16.4ft/ Customized | |
| Inner Box: | L315*W250*H160 mm / L12.40"*W9.84"*H6.30" | |
| Outer Carton: | L655*W525*H350 mm / L25.79"*W20.67"* H13.78" (8 pieces) | |
| Net Weight: | ≤ 5KG (1 pieces) | |
