Model:ZH1

ZH1, Type 1-Type 2 AC Charging Adapter

no data
Previous: No more data
Product Details
Electrical Parameters Work Voltage: AC 110V~250V
Rate Current: 32A MAX
Terminal Temp Rise: ＜50K
Withstand Voltage: 1500V
Material Parameters Case Material: PC+PA66+GF25%
Conductor: Copper alloy with silver plating
Coupled Insertion Force： 45N<F<100N
No-Load Plugin/Out: >10,000 times
Environmental Parameters  Work Temperature: -22°F~+122°F(-30℃~+50°C)
 Work Humidity: 5%~95%
Work Altitude: ≤ 2000 Meter
IP Code IP55/IP67 (Optional)
Certification  FCC
Size&Package Product Size: L:166.7*W:70.0*H:69.9mm
 Inner Box: L:186.0*W:75.0*H:75.0mm
Outer Carton:(10 pieces) L:400.0*W:210.0*H:175.0mm
 Net Weight: (1 pieces) ≤ 1KG
Electrical Parameters Work Voltage: AC 110V~250V
Rate Current: 32A MAX
Terminal Temp Rise: ＜50K
Withstand Voltage: 1500V
Material Parameters Case Material: PC+PA66+GF25%
Conductor: Copper alloy with silver plating
Coupled Insertion Force： 45N<F<100N
No-Load Plugin/Out: >10,000 times
Environmental Parameters  Work Temperature: -22°F~+122°F(-30℃~+50°C)
 Work Humidity: 5%~95%
Work Altitude: ≤ 2000 Meter
IP Code IP55/IP67 (Optional)
Certification  FCC
Size&Package Product Size: L:166.7*W:70.0*H:69.9mm
 Inner Box: L:186.0*W:75.0*H:75.0mm
Outer Carton:(10 pieces) L:400.0*W:210.0*H:175.0mm
 Net Weight: (1 pieces) ≤ 1KG
