Model:ZH13

ZH13, NACS-CCS 1 DC Charging Adapter

no data
Product Details
Electrical Parameters Work Voltage: DC 1000V
Rate Current: 500A MAX
Terminal Temp Rise: ＜50K
Withstand Voltage: 1500V
Material Parameters Case Material: PC+PA66+GF25%
Conductor: Copper alloy with silver plating
Coupled Insertion Force： 45N<F<100N
No-Load Plugin/Out: >10,000 times
Environmental Parameters  Work Temperature: -22°F~+122°F(-30℃~+50°C)
 Work Humidity: 5%~95%
Work Altitude: ≤ 2000 Meter
IP Code IP65
Certification  FCC
Size&Package Product Size: L:176.3*W:69.0*H:105.8mm
 Inner Box:
Outer Carton:(10 pieces)
 Net Weight: (1 pieces) ≤ 2KG
Electrical Parameters Work Voltage: DC 1000V
Rate Current: 500A MAX
Terminal Temp Rise: ＜50K
Withstand Voltage: 1500V
Material Parameters Case Material: PC+PA66+GF25%
Conductor: Copper alloy with silver plating
Coupled Insertion Force： 45N<F<100N
No-Load Plugin/Out: >10,000 times
Environmental Parameters  Work Temperature: -22°F~+122°F(-30℃~+50°C)
 Work Humidity: 5%~95%
Work Altitude: ≤ 2000 Meter
IP Code IP65
Certification  FCC
Size&Package Product Size: L:176.3*W:69.0*H:105.8mm
 Inner Box:
Outer Carton:(10 pieces)
 Net Weight: (1 pieces) ≤ 2KG
